POWER
200 watts RMS per channel into 8 ohms.
280 watts RMS per channel into 4 ohms.
Both channels driven from 20Hz to 20kHz at less than 0.2% total harmonic distortion
FREQUENCY RESPONSE
20Hz to 20kHz ±0.2dB
-3dB at 5Hz and -3dB at 70kHz
DISTORTION
Typically <0.05% THD at rated power
0.2% THD and IM worst case prior to clipping
CURRENT OUTPUT
40A short duration peak per channel
Fuse protected
SLEW RATE
50V/µs
HUM & NOISE
90dB below rated output 20Hz to 20kHz unweighted
INPUT IMPEDENCE
47k ohms all inputs
Phono adjustable to 47k ohms, 470 ohms,
100 ohms,47 ohms, 22 ohms
RATED PRE OUT LEVEL
1.5V RMS into 47k ohms or higher
PRE OUT SOURCE IMPEDENCE
Typically 1.5k ohms
PRE OUT MINIMUM RECOMMENDED LOAD
47k ohms
LINE OUT LEVEL
190mV at 200 ohms
GAIN
Line inputs to speaker out: 40dB
Phono Input To Pre-Out: 66dB on high gain, 60dB on low gain
POWER/CURRENT CONSUMPTION
600W
0.4A (92W)
Class AB Idle 0.14A (32W) Standby
DIMENSIONS
Height: 120mm (4 3/4")
Width: 450mm (17 3/4")
Depth: 400mm (15 3/4")
Weight: 14kg (30lb)
)
!
