Drivers
1 x 25mm ( 1") Wilson Benesch Semisphere tweeter
2 x 170mm ( 7") Wilson Benesch Tactic II mid-range drive units
4 x 170mm ( 7") Wilson Benesch Tactic II Isobaric bass drive units
2 x 170mm ( 7") Wilson Benesch Tactic II ABR drive units
CONSTRUCTION
Poly-alloy hybrid construction
High performance carbon composite A.C.T. monocoque
Lower mid range infinite baffle sealed enclosure
Upper mid range Tactic II ABR sealed enclosure
Isobaric drive chamber Tactic II ABR sealed enclosure.
4kg precision machined Isobaric drive sub baffle
Aerospace silk black baffle, spine and foot
High gloss satin weave carbon fibre cabinet
High gloss carbon fibre top
DIMENSIONS
Height: 1735mm ( 68.3")
Width: 620mm ( 24.4")
Depth: 640mm ( 25.2")
Volume: 92L
Weight per channel: 180kg (397 lbs)
2-way electric, 4-way acoustic, floor standing loudspeaker
Impedance: 6Ω nominal / 3Ω minimal
Sensitivity: 90dB at 1 metre on-axis, 2.83V input
Frequency response: 25Hz - 30kHz +/- 2dB on-axis
Minimum amplification power recommendation: 100 W / channel
Crossover frequency: 500Hz / 5kHz
)
!
