Specifications Description 3-way vented-box system Dimensions Height: 1197mm (47.1in) Width: 450mm (17.7in) Depth: 646mm (25.4in) Net Weight 125kg / 275lb Frequency Response 37Hz - 23kHz ± 2dB on reference axis Frequency Range -6dB at 25Hz and 50kHz -3dB at 32Hz and 42kHz Sensitivity 91dB spl (2.83V 1m) Nominal Impedance 8 ohms (minimum 3 ohms) Power Handling 50 - 1000W into 8 ohms on unclipped programme Drive Units 1x 25mm (1in) metal dome high-frequency 1x 150mm (6in) woven Kevlar® cone midrange 2x 250mm (10in) paper/Kevlar® cone bass Finish Cabinet: Real wood veneers Grey Tigers Eye Dispersion Within 2dB of response on reference axis Horizontal: over 60° arc Vertical: over 10° arc Harmonic distortion 2nd and 3rd harmonics (90dB, 1m) <1.0% 45Hz - 20kHz <0.5% 50Hz - 20kHz Crossover frequencies 350Hz and 4kHz Max. recommended cable impedance 0.1 ohms
