SPEAKER TYPE

• 3-way DSP active loudspeaker with controller supporting analog, digital, phono and Roon Ready streaming inputs

DRIVERS

• 26 mm (1”) proprietary YG Lattice hybrid tweeter with advanced airframe
• Dual 15 cm (6”) proprietary YG aluminum cone midrange drivers with advanced neodymium motor magnets
• 26 cm (10.25”) proprietary YG aluminum cone bass drivers with ultra-high field strength motor

AMPLIFIER

• Dedicated 700 W amp per drive unit = 2.8 kW per channel
• 0.0006% THD+N 20 Hz to 20 kHz at half peak power
• 137 dB SNR unweighted ref. peak power
• 93% efficiency at peak power
• 250 μΩ output impedance

RESPONSE

• Usable output extends from 20 Hz to 40 kHz
• Exceptionally low distortion throughout range

CROSSOVER

• Advanced DSP crossover optimized using supercomputer and cloud computing, then tuned across thousands of hours of critical listening. Exceptional phase, amplitude and impulse accuracy response at all volume levels.

DIGITAL INPUTS

• AES (XLR), SPDIF (BNC), TOSLINK, USB, Ethernet AES, SPDIF, TOSLINK: 24 bit up to 192 KS/s
• Ethernet: 24 bits to 192 KS/s and DSD64
• USB2 Audio: 24 bits to 384 KS/s and DSD64/128 (DoP)

ANALOG INPUTS

• 2 × Line inputs RCA
• Maximum input: 2.2 Vrms
• Input Impedance: 10 kΩ

PHONO INPUT

• Sensitivity: MM: 2.5 mV to 5 mV; MC: 0.25 mV to 0.5 mV
• Input load: MM: 47 kΩ; MC: 50 Ω, 100 Ω, 500 Ω, 1 kΩ
• RIAA Accuracy: +/-0.25 dB, 50 Hz – 15 kHz
• THD+N: <0.01% 1 kHz A-weighted SNR: >70 dB A-weighted
• SNR: >70 dB A-weighted

GENERAL

• Controller: 94 × 400 × 316 mm [3.7 × 15.7 × 12.4”] H × W × D
• Controller weight: 8.7 kg [19.2lbs] unpacked
• Speaker: 148 × 35 × 64 cm [58 × 14 × 25”] H × W × D
• Speaker weight: 120 kg [264 lbs] per channel unpackaged

FINISHES

• Standard finishes are silver and black
• Please contact your dealer for other finish options
